Yükleme Dosyaları
| Class | Date | Title | Language | Type | Download |
|---|---|---|---|---|---|
| Datasheet | 2017-02-16 | DH-IPC-HUM8230_Datasheet_20170216 | English |  |
| Class | Date | Title | Language | Type | Download |
|---|---|---|---|---|---|
| User Manual | 2017-02-16 | DH-IPC-HUM8230_QuickStartGuide_20170216 | English | |
|
| User Manual | 2017-02-16 | DH-IPC-HUM8230_Operation_Manual_20170216 | English | |
| Class | Date | Title | Language | Type | Download |
|---|---|---|---|---|---|
| Drawings | 2017-02-16 | DH-IPC-HUM8230_Dimension_20170216 | English | |
|
| Drawings | 2017-02-16 | DH-IPC-HUM8230_Installation_20170216 | English | |
| Title | Remark | Release notes | Download |
|---|---|---|---|
| Images | 2016-04-01 | IPC-HUM8230 |  |
| Title | Remark | Release notes |
|---|---|---|
| [NTSC]DH_IPC-HX5X3X-Rhea_EngSpnFrn_N_Stream3_V2.460.0000000.16.R.20170904 | |
|
| [PAL]DH_IPC-HX5X3X-Rhea_Eng_P_Stream3_V2.460.0000000.16.R.20170904 | |
|
| [NTSC]DH_IPC-HX5X3X-Rhea_EngSpnFrn_N_Stream3_V2.460.0000000.16.R.20170904 | |
Teknik Özellikler
| Camera | |
| Image Sensor | 1/2.8” 2Megapixel progressive scan CMOS |
| Effective Pixels | 1920(H)x1080(V) |
| RAM/ROM | 256MB/32MB |
| Scanning System | Progressive |
| Minimum Illumination | L1: 0.07Lux/F2.4 (Color), 0.007Lux/F2.4 (B/W)
L3: 0.009Lux/F1.8 (Color), 0.001Lux/F1.8 (B/W) |
| S/N Ratio | More than 50dB |
| IR Distance | N/A |
| IR On/Off Control | N/A |
| IR LEDs | N/A |
| Lens | |
| Lens Type | Fixed |
| Mount Type | Board-in |
| Focal Length | 2.8mm |
| Max. Aperture | Sensor Unit L1:F2.4
Sensor Unit L3:F1.8 |
| Angle of View | Sensor Unit L1 H:104° ,V:57°
Sensor Unit L3 H:118° ,V:60° |
| Optical Zoom | N/A |
| Focus Control | Fixed |
| Close Focus Distance | N/A |
| Pan/Tilt/Rotation | |
| Pan/Tilt/Rotation Range | N/A |
| Intelligence | |
| IVS (optional) | Tripwire, Intrusion, Object Abandoned/Missing |
| Advanced Intelligent Functions | Face Detection |
| Video | |
| Compression | H.265+/H.265/H.264+/H.264 |
| Streaming Capability | 3 Streams |
| Resolution | 1080P(1920×1080)/ 1.3M(1280×960)/ 720P(1280×720)/ D1(704×576/704×480)/ VGA(640×480)/ CIF(352×288/342×240) |
| Frame Rate | Main Stream: 1080P(1~25/30fps) |
| Sub Stream: D1 (1 ~ 25/30fps) | |
| Third Stream: 1080P(1~25/30fps) | |
| Bit Rate Control | CBR/VBR |
| Bit Rate | H.264: 24Kbps~ 9472Kbps
H.265: 14Kbps~ 5632Kbps |
| Day/Night | Electronic |
| BLC Mode | BLC / HLC / DWDR |
| White Balance | Auto/Natural/Street Lamp/Outdoor/Manual |
| Gain Control | Auto/Manual |
| Noise Reduction | 3D DNR |
| Motion Detetion | Off / On (4 Zone, Rectangle) |
| Region of Interest | Off / On (4 Zone) |
| Electronic Image Stabilization (EIS) | N/A |
| Smart IR | N/A |
| Defog | N/A |
| Digital Zoom | 16x |
| Flip | 0°/90°/180°/270° |
| Mirror | Off / On |
| Privacy Masking | Off / On (4 Area, Rectangle) |
| Audio | |
| Compression | G.711a/ G.711Mu/ AAC/ G.726 |
| Network | |
| Ethernet | RJ-45 (10/100Base-T) |
| Protocol | HTTP;HTTPs;TCP;ARP;RTSP;RTP;UDP;SMTP;FTP;
DHCP;DNS;DDNS;PPPOE;IPv4/v6;QoS;UPnP;NTP; Bonjour;802.1x;Multicast;ICMP;IGMP;SNMP |
| Interoperability | ONVIF, PSIA, CGI |
| Streaming Method | Unicast / Multicast |
| Max. User Access | 10 Users/20 Users |
| Edge Storage | NAS
Local PC for instant recording Mirco SD card 128GB |
| Web Viewer | IE, Chrome, Firefox, Safari |
| Management Software | Smart PSS, DSS, Easy4ip |
| Smart Phone | IOS, Android |
| Certifications | |
| Certifications | CE (EN 60950:2000)
UL:UL60950-1 FCC: FCC Part 15 Subpart B |
| Interface | |
| Video Interface | N/A |
| Audio Interface | 1/1 channel In/Out |
| RS232 | 1 port |
| Alarm | 2/2 channel In/Out |
| Electrical | |
| Power Supply | DC12V, PoE(802.3af)(Class 0) |
| Power Consumption | <6W |
| Environmental | |
| Operating Conditions | -30° C ~ +60° C (-22° F ~ +140° F) / Less than 95% RH |
| Strorage Conditions | -30° C ~ +60° C (-22° F ~ +140° F) / Less than 95% RH |
| Ingress Protection | N/A |
| Vandal Resistance | N/A |
| Construction | |
| Casing | Metal |
| Dimensions | Main Unit:110.0mm×82.7mm×24.0mm (4.33”×3.26”×0.95”)
Sensor Unit L1:Φ26.5mm×48.31mm(Φ1.04”×1.9”) Sensor Unit L3:Φ26.5mm×50.38mm(Φ1.04”×2.0”) |
| Net Weight | Main Unit:0.2Kg (lb)
Sensor Unit L1:0.22Kg (lb) Sensor Unit L3:0.235Kg (lb) |
| Gross Weight | Main Unit:0.36Kg (lb)
Sensor Unit L1:0.31Kg (lb) Sensor Unit L3:0.325Kg (lb) |
