Camera Image Sensor 1/1.9” 2Megapixel progressive scan CMOS Effective Pixels 1920(H)x1080(V) RAM/ROM 1024MB/128MB Scanning System Progressive Electronic Shutter Speed Auto/Manual, 1/3~1/100000s Minimum Illumination 0.002Lux/F1.53 (Color,1/3s,30IRE) 0.01Lux/F1.53 (Color,1/30s,30IRE)
0Lux/F1.53(IR on)
S/N Ratio More than 50dB IR Distance Distance up to 50m(164ft) IR On/Off Control Auto/ Manual IR LEDs 4 Lens Lens Type Motorized /Auto Iris(HALL) Mount Type Board-in Focal Length 4.1~16.4mm motorized Max. Aperture F1.53 Angle of View H: 80°~32°, V:47°~18° Optical Zoom 4x Focus Control Motorized Close Focus Distance 0.5m(1.64ft) DORI Distance Lens Detect Observe Recognize Identify W 57m(187ft) 23m(75ft) 11m(36ft) 6m(20ft) T 137m(449ft) 55m(180ft) 27m(89ft) 14m(49ft) Pan/Tilt/Rotation Pan/Tilt/Rotation Range Pan:0˚~360˚; Tilt:0˚~90˚; Rotation:0˚~360˚ Intelligence IVS Tripwire, Intrusion, Object Abandoned/Missing Advanced Intelligent Functions Face Detection, People Counting, Heat Map Video Compression H.265+/H.265/H.264+/h.264 Streaming Capability 3 Streams Resolution 1080P(1920×1080)/ 1.3M(1280×960)/ 720P(1280×720)/ D1(704×576/704×480) / VGA(640×480)/ CIF(352×288/342×240) Frame Rate Main Stream: 1080P(1~50/60fps) Sub Stream: D1 (1 ~ 50/60fps) Third Stream: 1080P(1~50/60fps) Bit Rate Control CBR/VBR Bit Rate H.264: 24~ 10240Kbps H.265: 14~ 6144Kbps
Day/Night Auto(ICR) / Color / B/W BLC Mode BLC / HLC / WDR(120dB)/ SSA White Balance Auto/Natural/Street Lamp/Outdoor/Manual Gain Control Auto/Manual Noise Reduction 3D DNR Motion Detetion Off / On (4 Zone, Rectangle) Region of Interest Off / On (4 Zone) Electronic Image Stabilization (EIS) Support Smart IR Support Defog Support Digital Zoom 16x Flip 0°/90°/180°/270° Mirror Off / On Privacy Masking Off / On (4 Area, Rectangle) Audio Compression G.711a/G.711Mu/AAC/ G.726 Network Ethernet RJ-45 (100/1000Base-T) Protocol HTTP;HTTPs;TCP;ARP;RTSP;RTP;UDP;SMTP;FTP; DHCP;DNS;DDNS;PPPOE;IPv4/v6;QoS;UPnP;NTP;
Bonjour;802.1x;Multicast;ICMP;IGMP;SNMP
Interoperability ONVIF, PSIA, CGI Streaming Method Unicast / Multicast Max. User Access 10 Users/20 Users Edge Storage NAS Local PC for instant recording
Mirco SD card 128GB
Web Viewer IE, Chrome, Firefox, Safari Management Software Smart PSS, DSS, Easy4ip Smart Phone IOS, Android Certifications Certifications CE (EN 60950:2000) UL:UL60950-1
FCC: FCC Part 15 Subpart B
Interface Video Interface 1 Port(For adjustment only) Audio Interface 1/1 channel In/Out RS485 N/A Alarm 2 channel In: 5mA 5VDC 1 channel Out: 1A 30VDC / 0.5A 50VAC
Electrical Power Supply DC12V, PoE+(802.3at)(Class 4) Power Consumption <13W Environmental Operating Conditions -40° C ~ +60° C (-40° F ~ +140° F) / Less than 95% RH Strorage Conditions -40° C ~ +60° C (-40° F ~ +140° F) / Less than 95% RH Ingress Protection IP67 Vandal Resistance IK10 Construction Casing Metal Dimensions 273.2mm×95.0mm×96.4mm (10.76”×3.74”×3.79”) Net Weight 1.12Kg (2.47lb) Gross Weight 1.52Kg (3.35lb)
