| Camera |
| Image Sensor |
1/2.9” 6Megapixel progressive scan CMOS |
| Effective Pixels |
3072(H) x 2048(V) |
| RAM/ROM |
512MB/32MB |
| Scanning System |
Progressive |
| Electronic Shutter Speed |
Auto/Manual, 1/3(4)~1/100000s |
| Minimum Illumination |
0.04Lux/F1.6( Color,1/3s,30IRE)
0.4Lux/F1.6( Color,1/30s,30IRE)
0Lux/F1.6(IR on) |
| S/N Ratio |
More than 50dB |
| IR Distance |
Distance up to 40m (131ft) |
| IR On/Off Control |
Auto/ Manual |
| IR LEDs |
2 |
| Lens |
| Lens Type |
Fixed |
| Mount Type |
Board-in |
| Focal Length |
2.8mm (3.6mm optional) |
| Max. Aperture |
F1.6(F1.6) |
| Angle of View |
H: 98° (69°), V: 67° (48°) |
| Optical Zoom |
N/A |
| Focus Control |
Fixed |
| Close Focus Distance |
0.9m(1.7m) |
| DORI Distance |
Lens |
Detect |
Observe |
Recognize |
Identify |
| 2.8 mm |
69m(226ft) |
28m(92ft) |
14m(46ft) |
7m(23ft) |
| 3.6 mm |
89m(292ft) |
36m(118ft) |
18m(59ft) |
9m(30ft) |
| Pan/Tilt/Rotation |
| Pan/Tilt/Rotation Range |
Pan:0˚~360˚; Tilt:0˚~90˚; Rotation:0˚~360˚ |
| Intelligence |
| IVS |
Tripwire, Intrusion, Object Abandoned/Missing |
| Advanced Intelligent Functions |
Face Detection |
| Video |
| Compression |
H.265+/H.265/H.264+/H.264 |
| Streaming Capability |
3 Streams |
| Resolution |
(3072×2048)/(3072×1728)/(2592×1944)/(2688×1520)/(2560×1440)/(2304×1296)/1080P(1920×1080)/SXGA(1280×1024)/1.3M(1280× 960)/720P(1280×720)/D1(704×576/704×480)/CIF(352×288/352×240) |
| Frame Rate |
Main Stream: 6MP (1~20fps), 4MP(1~25/30fps) |
| Sub Stream: D1(1~25/30fps) |
| Third Stream: 1080P(1~25/30fps) |
| Bit Rate Control |
CBR/VBR |
| Bit Rate |
H.264: 24K ~ 10240Kbps
H.265: 14K ~ 9984Kbps |
| Day/Night |
Auto(ICR) / Color / B/W |
| BLC Mode |
BLC / HLC / WDR(120dB) |
| White Balance |
Auto/Natural/Street Lamp/Outdoor/Manual |
| Gain Control |
Auto/Manual |
| Noise Reduction |
3D DNR |
| Motion Detetion |
Off / On (4 Zone, Rectangle) |
| Region of Interest |
Off / On (4 Zone) |
| Electronic Image Stabilization (EIS) |
N/A |
| Smart IR |
Support |
| Defog |
N/A |
| Digital Zoom |
16x |
| Flip |
0°/90°/180°/270° |
| Mirror |
Off / On |
| Privacy Masking |
Off / On (4 Area, Rectangle) |
| Audio |
| Compression |
N/A |
| Network |
| Ethernet |
RJ-45 (10/100Base-T) |
| Protocol |
HTTP; HTTPs; TCP; ARP; RTSP; RTP; UDP; SMTP;
FTP; DHCP; DNS; DDNS; PPPOE; IPv4/v6; QoS;
UPnP;NTP; Bonjour; 802.1x; Multicast; ICMP;
IGMP; SNMP |
| Interoperability |
ONVIF, PSIA, CGI |
| Streaming Method |
Unicast / Multicast |
| Max. User Access |
10 Users /20 Users |
| Edge Storage |
NAS
Local PC for instant recording
Mirco SD card 128GB |
| Web Viewer |
IE, Chrome, Firefox, Safari |
| Management Software |
Smart PSS, DSS, Easy4ip |
| Smart Phone |
IOS, Android |
| Certifications |
| Certifications |
CE (EN 60950:2000)
UL:UL60950-1
FCC: FCC Part 15 Subpart B |
| Interface |
| Video Interface |
N/A |
| Audio Interface |
N/A |
| RS485 |
N/A |
| Alarm |
N/A |
| Electrical |
| Power Supply |
DC12V, PoE (802.3af)(Class 0) |
| Power Consumption |
<6.5W |
| Environmental |
| Operating Conditions |
-30° C ~ +60° C (-22° F ~ +140° F) / Less than 95% RH |
| Strorage Conditions |
-30° C ~ +60° C (-22° F ~ +140° F) / Less than 95% RH |
| Ingress Protection |
IP67 |
| Vandal Resistance |
N/A |
| Construction |
| Casing |
Metal |
| Dimensions |
180mm×70mm×70mm (7.09”×2.76”×2.76”) |
| Net Weight |
0.41kg (0.91lb) |
| Gross Weight |
0.53 kg (1.17lb) |
|
